Showing Settings from macOS Menu Bar Items: A 5-Hour Journey

Published:
7 min read

Opening a settings window from a macOS menu bar app should be trivial. It’s not. After spending hours debugging, I’m documenting the gotchas to save you the same frustration.

The Problem

SwiftUI provides SettingsLink for opening settings:

MenuBarExtra("Test", systemImage: "star.fill") {
    SettingsLink {
        Text("Open settings")
    }
}

Simple, right? Except it doesn’t work reliably in MenuBarExtra. The documentation doesn’t mention this limitation.

According to Apple’s documentation, SettingsLink should “open the app’s settings scene when activated.” However, this assumes your app is already active and has proper window management context - assumptions that don’t hold for menu bar apps.

Why It Fails

Menu bar apps operate differently from regular macOS apps:

The root issue is that NSApplication treats menu bar apps as background utilities, not foreground applications. This affects how windows are ordered and receive events.

The Evolution of Workarounds

The Old Way

This is how it used to work. Private API, but widely used and simple:

if #available(macOS 13, *) {
    NSApp.sendAction(Selector(("showSettingsWindow:")), to: nil, from: nil)
} else {
    // macOS 12 or earlier
    NSApp.sendAction(Selector(("showPreferencesWindow:")), to: nil, from: nil)
}

This stopped working in Sonoma (14) with the error: “Please use SettingsLink for opening the Settings scene.” Apple deprecated these selectors in favor of SwiftUI’s scene-based approach, but didn’t account for the unique challenges of menu bar apps.

The openSettings Environment Action

Apple provides an openSettings environment action for programmatic access (available since macOS 14.0+):

struct MyView: View {
    @Environment(\.openSettings) private var openSettings

    var body: some View {
        Button("Open Settings") {
            openSettings()
        }
    }
}

This currently works on macOS 15, but doesn’t work on macOS Tahoe (26). The logic needs an existing SwiftUI render tree, and simply calling the environment variable does nothing if none is found.

The workaround? As horrible as it sounds, a hidden window. Of course, that comes with its own issues, unless you massage the window that it’s really off-screen and ideally also doesn’t react to touches.

Hide & Seek

Now, this works, however the window will open in the background, and no amount of makeKeyAndOrderFront(nil) will help. Trust me. I (and Claude) tried plenty variations.

The real reason? macOS doesn’t allow a window to become selected when there’s no Dock icon. And since it’s common to hide the Dock icon for pure Menu Bar apps, that’s a problem.

The workaround? Show the Dock icon just before calling openSettings() and then hiding it again. In a way, this is also convenient for the user as the Icon now represents the “app” - the visible window, and once that closes, we hide the Dock icon again. (via calling NSApp.setActivationPolicy(.accessory)). Of course the whole thing requires some delays to really work, so let me present you the final, working solution (I apologize in advance):

The Working Solution

Here’s the minimal implementation for macOS 14 and higher, using Swift 6:

// Hidden window to provide context
struct HiddenWindowView: View {
    @Environment(\.openSettings) private var openSettings

    var body: some View {
        Color.clear
            .frame(width: 1, height: 1)
            .onReceive(NotificationCenter.default.publisher(for: .openSettingsRequest)) { _ in
                Task { @MainActor in
                    // Show dock icon for window focus
                    NSApp.setActivationPolicy(.regular)
                    try? await Task.sleep(for: .milliseconds(100))

                    // Activate and open
                    NSApp.activate(ignoringOtherApps: true)
                    openSettings()

                    // 2. No window ordering - After openSettings(), you might need additional window management to ensure
                    // it comes to front:
                    try? await Task.sleep(for: .milliseconds(200))
                    if let settingsWindow = findSettingsWindow() {
                        settingsWindow.makeKeyAndOrderFront(nil)
                        settingsWindow.orderFrontRegardless()
                    }
                }
            }
            .onReceive(NotificationCenter.default.publisher(for: .settingsWindowClosed)) { _ in
                // Restore menu bar app state when settings closes
                NSApp.setActivationPolicy(.accessory)
            }
    }
}

// Window identifier for settings
static let settingsWindowIdentifier = "com.apple.SwiftUI.Settings"

/// Finds the settings window using multiple detection methods
static func findSettingsWindow() -> NSWindow? {
    // Try multiple methods to find the window
    return NSApp.windows.first { window in
        // Check by identifier
        if window.identifier?.rawValue == settingsWindowIdentifier {
            return true
        }

        // Check by title
        if window.isVisible && window.styleMask.contains(.titled) &&
           (window.title.localizedCaseInsensitiveContains("settings") ||
            window.title.localizedCaseInsensitiveContains("preferences")) {
            return true
        }

        // Check by content view controller type
        if let contentVC = window.contentViewController,
           String(describing: type(of: contentVC)).contains("Settings") {
            return true
        }

        return false
    }
}

// App structure
@main
struct MenuBarApp: App {
    var body: some Scene {
        MenuBarExtra("My App", systemImage: "star.fill") {
            Button("Settings...") {
                NotificationCenter.default.post(name: .openSettingsRequest, object: nil)
            }
            .keyboardShortcut(",", modifiers: .command)
        }

        // Required Settings scene
        Settings {
            SettingsView()
                .onDisappear {
                    NotificationCenter.default.post(name: .settingsWindowClosed, object: nil)
                }
        }

        // Hidden window for context
        Window("Hidden", id: "HiddenWindow") {
            HiddenWindowView()
        }
        .windowResizability(.contentSize)
        .defaultSize(width: 1, height: 1)
    }
}

extension Notification.Name {
    static let openSettingsRequest = Notification.Name("openSettingsRequest")
    static let settingsWindowClosed = Notification.Name("settingsWindowClosed")
}

The NotificationCenter approach decouples the menu action from the window context, allowing the hidden window to handle the actual settings opening.

For a production-ready implementation with all edge cases (yes, there are some more…) handled, see VibeTunnel’s SettingsOpener.swift.

Scene Order Matters (Unfortunately)

While implementing @steipete’s solution described above, I (@matejkob) discovered another gotcha: the order of scenes in your App’s body actually affects whether this workaround functions correctly.

The working example shown earlier has the scenes in this order:

  1. MenuBarExtra
  2. Settings
  3. Window (hidden)

However, I found that if you arrange them like this (which seems equally logical):

var body: some Scene {
    MenuBarExtra("My App", systemImage: "star.fill") {
        ContentView()
    }
    .menuBarExtraStyle(.menu)

    Settings {
        SettingsView()
            .onDisappear {
                NotificationCenter.default.post(name: .settingsWindowClosed, object: nil)
            }
    }

    // Hidden window for settings context
    Window("Hidden", id: "HiddenWindow") {
        HiddenWindowView()
    }
    .windowResizability(.contentSize)
    .defaultSize(width: 100, height: 100)
}

The hidden window won’t be “visible” to the SwiftUI environment system (at least not on macOS Sequoia 15.5), and the openSettings() call will fail silently. However, moving the hidden Window scene before the Settings scene makes it work perfectly:

var body: some Scene {
    // Hidden window for settings context - MUST come before Settings
    Window("Hidden", id: "HiddenWindow") {
        HiddenWindowView()
    }
    .windowResizability(.contentSize)
    .defaultSize(width: 100, height: 100)

    MenuBarExtra("My App", systemImage: "star.fill") {
        ContentView()
    }
    .menuBarExtraStyle(.menu)

    Settings {
        SettingsView()
            .onDisappear {
                NotificationCenter.default.post(name: .settingsWindowClosed, object: nil)
            }
    }
}

This suggests that SwiftUI’s scene resolution and environment propagation happens in declaration order, and the @Environment(\.openSettings) action in the hidden window needs its context established before the Settings scene is processed.

Whether this is an Xcode build system quirk, a SwiftUI implementation detail, or intended behavior is unclear from Apple’s documentation. What is clear is that the hidden window must be declared before the Settings scene for this workaround to function reliably.

This adds yet another layer of undocumented complexity to what should be a simple operation - not only do we need a hidden window and activation policy juggling, but we also need to carefully order our scene declarations to avoid mysterious failures.

Understanding the Workaround

The hidden window serves multiple purposes:

The dock icon manipulation (switching between .accessory and .regular) is necessary because macOS only brings windows to the front reliably for apps with dock icons.

Fin

What should be a one-liner in other frameworks requires careful orchestration in SwiftUI. The combination of MenuBarExtra, Settings scenes, and openSettings wasn’t designed with the unique constraints of menu bar apps in mind.

This shouldn’t be so hard. Opening a settings window is one of the most basic operations any app needs to perform. The fact that it requires hidden windows, activation policy juggling, and precise timing delays in 2025 is a testament to how menu bar apps remain second-class citizens in SwiftUI. Until Apple addresses these fundamental issues, we’re stuck with these workarounds.
